9-SPECIFICATIONS

Axles

Frontaxles

Front2WD/2WSAxle(580T)

Model

CNH

Type

Steering

Front4WD/2WSAxle(580ST/590ST)

Model

CNH

Type

Steering

Front4WD/4WSAxle(695ST)

Model

CARRARO26.32

Type

Steering

Rearaxles

Rearaxle2WS

Model(580T/580ST))CARRARO28.44

Model(590ST)CARRARO28.50

TypeRigid

Rear4WSAxle(695ST)

Model

CARRARO26.43M

Type

Steering

Differentiallock

Electrical

9-8
