9-SPECIFICATIONS

695ST

LEEN11T0032FA9

Maximumheightofloaderbucketpin/pivotwithliftedforks3520mm(138.6in)

Forkmaximumheight

3060mm(120.5in)

Heightofloaderbucketpin/pivotofloaderbucketwithloweredforks460mm(18.1in)

DForkreachwhenraised

2195mm(86.4in)

EForkreachwhenlowered

3185mm(125.4in)

9-22
