Engine-Engineandcrankcase
Engine-Remove
1.PreparetheengineforremovalasexplainedinEngine
-Prepareforremoval(10.001).
2.Removeanddisconnectcompressorelectricalconnec-
torX-473(ifpresent).
LELI12TLB0038AA1
3.Identify,taganddisconnectthehighpressureandlow
pressureairconditioninglines,(ifpresent).
LEPH12TLB0039AA2
4.DisconnecttheairtemperaturesensorX-474.
LEPH12TLB0040AA3
4784714624/06/2015
10.1[10.001]/8
