Engine-Aftercooler
10.Loosentheclampattheelbow-turbochargerconnec-
tionend.Removetubeandplugturbocharger.
RAPH12WEL0206AA9
Intakeporttuberemoval
11.Loosentoprightsideclampsoftheaircoolerintake
hose.Slidehosebackfarenoughtoclearaircooler
tube.
RAPH12WEL0200AA10
12.Loosenendclamponintakeportsideoftheengine.
Removetubewithhose.
RAPH12WEL0202AA11
7111402215/02/2016
10.3[10.310]/6
