Engine-Aftercooler
7.Removecotterpinandpinfromtheliftcylinder.Turn
electricalmasterswitchbackonandrunliftcylinderup.
Oncecylinderisretracted,returntheelectricalmaster
switchbacktotheOFFposition.
RAPH12WEL0191AA6
8.Removethehoodbracketboltsandmovehoodaway
frombackplate,allowingenoughclearancetoreachair
coolerunitfrontbolts.
RAPH12WEL0169AA7
Turbochargertuberemoval
9.Loosentopleftsideclampoftheaircooleroutlethose.
NOTE:Loosenonlytheclampclosesttotheaircooler.
RAPH12WEL0207AA8
7111402215/02/2016
10.3[10.310]/5
