Case 921E - Page 35

2000-13
Bur 5-5410 Issued 2-07 Printed in U.S.A.
Installation
BS07B492
1. NUT 4. ISOLATOR UPPER 7. ENGINE MOUNT BOLT 10. WASHER
2. WASHER 5. ISOLATOR LOWER 8. ENGINE MOUNT PLATE 11. BOLT
3. WASHER 6. WASHER 9. NUT
1
7
8
2
3
4
5
6
9
10
10
11
