Case C12000ES - Generator Components

13
GENERATOR COMPONENTS
The following diagram is intended for general reference
purposes only. Your unit may differ in several aspects.
For specific model information, please visit:
CNHPOWEREQUIPMENT.COM
1. Control Panel
2. Fuel Tank
3. Fuel Gauge
4. Oil Drain Plug
5. Recoil Starter
6. Tank Cap
7. Frame
8. Air Cleaner
9. Battery
10. ON/OFF Switch
11. DC Connection
12. DC Breaker
13. Hour Meter
14. 120V 30A 3-Prong Twistlock
15. 120V/240V 4-Prong Push Plug
16. 120V GFCI
17. Main Circuit Breaker
18. Wheel Kit
19. Oil Dipstick
20. Handles
