SECTION 00 - INTRODUCTION 21
TRAVEL MOTOR
TRAVEL MOTOR “HIGH SPEED”
3.10 ELECTRICAL SYSTEM (EUROPE MODELS)
STANDARD ELECTRICAL SYSTEM
Service voltage ............................................................................................................................................ 12 V
Battery (quantity 1)
Capacity (20 h)........................................................................................................................................... 95 Ah
Discharge current....................................................................................................................................... 900 A
Weight (with electrolyte).................................................................................................................. 25 kg (55 lb)
ELECTRICAL SYSTEM WITH COLD START DEVICE
Service voltage ............................................................................................................................................ 12 V
Battery (quantity 2)
Capacity (20 h)......................................................................................................................................... 155 Ah
Discharge current..................................................................................................................................... 1050 A
Weight (with electrolyte)............................................................................................................. 45,4 kg (100 lb)
3.11 ELECTRICAL SYSTEM (NORTH AMERICA MODELS)
Service voltage ............................................................................................................................................ 12 V
Battery
Capacity (20 h)........................................................................................................................................... 95 Ah
Critical current............................................................................................................................................ 900 A
Weight............................................................................................................................................. 25 kg (55 lb)
21E 121E 221E 321E
Type A6VM80HA1U1 / 63W A6VM107HA1U1 / 63W
Displacement Q
max
/ Q
min
cm
3
(in
3
)
80 / 18.8
(4.88 / 1.14)
80 / 23.7
(4.88 / 1.44)
80 / 24.8
(4.88 / 1.51)
107 / 34.5
(6.52 / 2.10)
Maximum speed rpm 4352 5289 5289 4811
Delivery pressure bar
(psi)
25
(362)
25
(362)
25
(362)
25
(362)
Service pressure bar
(psi)
245
(3552)
190
(2755)
245
(3552)
215
(3117)
Pressure increasing spring bar
(psi)
10
(145)
10
(145)
10
(145)
10
(145)
Voltage V 12
121E 221E 321E
Type A6VM80HA1R1 / 63W
Displacement Q
max
/ Q
min
cm
3
(in
3
)
80 / 26.5 (4.88 / 1.62) 80 / 29.2 (4.88 / 1.78) 80 / 35.4 (4.88 / 2.16)
Maximum speed rpm 4770 4770 4770
Delivery pressure
bar (psi)
25
(362)
25
(362)
25
(362)
Service pressure
bar (psi)
190
(2755)
190
(2755)
215
(3117)
Pressure increasing spring
bar (psi)
10
(145)
10
(145)
10
(145)
Voltage V 12
