--rf
A
LITTLE DIRT CAN CRIPPLE
CHAINS
and
CABLES
Check
these high
quality
features:
.
Provides
constant
lubri€tion,
p€rmining
a
smmth
running
chain or €ble
.
Allows
maimum load
carrying capacrtaes
on
high or low sp6ed chains.
.
Reduces lrictaon drags on sudden
overloads
.
Preventsdripping on
slow speed
or idle cha,ns
.
Penetrates inward-llows freely into the
links
and strands.
.
Serues
the
purpo*
ol a
high
quality.ust
pre
ventive to exmsed o( idle chains and cables
.
Helps
prevent
cable and chain breakage and
oremature
failure.
Figure
B.
At
the end
of
the snow
season, the following
steps
are recommended:
1.
Remove the snorv blo.,ver from tractor
following
the
procedure
outlined at the
end
of this
manual.
2. Wash
off
any
salt
deposit which
may have
dried on
the auger
and
chute.
Paint
or
cover
exposed metal
with
a light
coat of
oil.
Case Touch-up
Enamel is avail-
able through
your
Case
Compact Trac-
tor
Dealer.
3. Service
the snow
blower
following
lubri-
cation instructions
above.
Oil the auger
drive
chain
thoroughly using
Case
Chain
and
cable Lubricant
to
prevent
rust
from
forming.
4" Store snow
blower in
a dry
place.
.
Giossier
Than lv'iost
.
Gloss
Lives
on
Whrle
Other
Chalk
.
Matches
Original
Parnl
.
Exceptional
Hiding Power
.
Same Formula
As
Ongrnal
Equipment
Paint
.
Outstanding Package
Siaortrry
CASE PAINT
is Tough
Stays
Glossy ls
Stable
Hides
Better Matches
the
Or
grnat
Case
Paint
goes
to Florida
to roox
b€tter
longer.
After
a
pajnt
sample
passes
the
Case weathercmeter
cy-
cle, it
must
endure
a more
severe
test In
sunny Flo|da
In lhe
sub-
troprcal
regron,
West
ol Miamr, the
deteriorating
action
of high tempera-
ture, relative
humrdity,
annual
rarn-
fall.
salt atmosphere
and solar
raora-
tion
combine to
attack
Case
parnr
Only the
best
paints
suryive to
earn
the
"Genuine"
Case Lab€l
Figure
9.
INSTALLATION
A. Locate the tractor on a smooth and
level
surface.
Check tires
for equal and
rec-
ommended
pressures.
t|lE
The^^front
tires should be inflated
to 20 nsi
when the
snow
blower
is
installld.
B.
Before attaching the snow blower, lay
out the
individual
parts
as illustrated
ir1
Figure
10.
To
simplify
the
original
installation,
aII
components
are
pre-
assembled as
far
as
practical
and
the
attaching
hardware
is
installed
in
its
proper
location.
Two
drive
belts
are
included
with the
48" Model
HB4 snow
blower so it
can be mounted
on
either
high or low
clearanee tractors.
C. The following installation
sequence is
the
same
whether
the tractor is
equipped
with hydraulic
or mechanical
lift.
