Case SPX Series - Steel Hydraulic Fittings - Flare and Straight Threads

1000 - 6
SPX 4260 Troubleshooting Manual
Issued 02-03 Printed in U.S.A. Standard Torque Specifications And Loctite Product Chart
TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS
37 Degree Flare Fitting Straight Threads with O-Ring
Tube OD
Hose ID
Thread
Size
Pound-
Inches
Newton
Metres
Tube OD
Hose ID
Thread
Size
Pound-
Inches
Newton
Metres
1/4 inch
6.4mm
7/16-20 72 to 144 8 to 16 1/4 inch
6.4mm
7/16-20 144 to 228 16 to 26
5/16 inch
7.9 mm
1/2-20 96 to 192 11 to 22 5/16 inch
7.9 mm
1/2-20 192 to 300 22 to 34
3/8 inch
9.5 mm
9/16-18 120 to 300 14 to 34 3/8 inch
9.5 mm
9/16-18 300 to 480 34 to 54
1/2 inch
12.7 mm
3/4-16 180 to 504 20 to 57 1/2 inch
12.7 mm
3/4-16 540 to 804 57 to 91
5/8 inch
15.9mm
7/8-14 300 to 696 34 to 79
Tube OD
Hose ID
Thread
Size
Pound-Feet Newton
Metres
Tube OD
Hose ID
Thread
Size
Pound-Feet Newton
Metres
5/8 inch
15.9mm
7/8-14 58 to 92 79 to 124
3/4 inch
19.0mm
1-1/16-12 40 to 80 54 to 108 3/4 inch
19.0mm
1-1/16-12 80 to 128 108 to 174
7/8 inch
22.2 mm
1-3/16-12 60 to 100 81 to 135 7/8 inch
22.2 mm
1-3/16-12 100 to 160 136 to 216
1.0 inch
25.4 mm
1-5/16-12 75 to 117 102 to 158 1.0 inch
25.4 mm
1-5/16-12 117 to 187 159 to 253
1-1/4 inch
31.8 mm
1-5/8-12 125 to 165 169 to 223 1-1/4 inch
31.8 mm
1-5/8-12 165 to 264 224 to 357
1-1/2 inch
38.1 mm
1-7/8-12 210 to 250 285 to 338 1-1/2 inch
38.1 mm
1-7/8-12 250 to 400 339 to 542
Split Flange Mounting Bolts
Size Pounds-Inches Newton Metres
5/16-18 180 to 240 20 to 27
3/8-16 240 to 300 27 to 34
7/16-14 420 to 540 47 to 61
Size
Pounds-Inches Newton Metres
1/2-13 55 to 65 74 to 88
5/8-11 140 to 150 190 to 203
