INTRODUCTION
3.Installtheretainingnuts.Torquethenutsto170N·m
(125lbft).
9310016339
Unlockandlowertheloaderarmformachineoperation
WARNING
Crushinghazard!Loaderarmsareunsup-
portedduringsupportstrutremoval.
Donotenterorexittheoperator'scompart-
mentwithanunsupportedloaderarm.Two
personsarerequiredduringstorage.Oneper-
sonshouldremoveandstorethesupportstrut
whiletheoperatorremainsintheoperator's
compartment.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0077B
NOTE:Aninstructionaldecalontheinsideoftheright-
handloaderarm,justabovethesupportstrutisalsoavail-
able.Understandtheloaderarmunlockprocedurebefore
continuing.
Placingthesupportstrutinthestoragepositionrequires
asecondperson.Theoperatormustremainintheseat
duringthisprocedure.
1.Sitintheoperator'sseat,fastentheseatbelt,pull
downtherestraintbardown,andstarttheengine.
2.Presstheoperatebuttontoenablethehydraulics.
3.Raisetheloaderarmuntilthesupportstrut(B)isnot
restingontheendofthecylinderbarrel(C).
RAIL14SSL0418AA10
93106854A11
4.Instructthesecondpersontoremovethesupportstrut
pin(A)andplacethesupportstrutinthestowedpo-
sitionandreinstallthesupportstrutpin(A).Whenthe
secondpersonhasclearedthearea,theoperatormay
nowlowertheloaderarm.
5.Commenceworkoperationsorparkthemachineand
stoptheengine.
93106848A12
4768391627/02/2015
11
