Case SR240 - Loader Arm Lock and Cab Tilt Procedure - Vertical Lift Machines

INTRODUCTION
Basicinstructions-Loaderarmlockandcabtiltprocedure-
verticalliftmachines
SV280TIER4B(FINAL)[NFM400877-]
WE
WARNING
Crushinghazard!
Donotenterorexittheoperator'scompartmentwhiletheloaderarmsareraisedorunsupported.Rest
theloaderarmsonthegroundorverifythatloaderarmisbeingsupportedbytheloaderarmstrutor
loaderarmlockpinbeforeenteringorexitingtheoperator'scompartment.
Failuretocomplycouldresultindeathorseriousinjury.
W1365A
Raiseandlocktheloaderarmformachineservice
1.Sitintheoperator'sseat,fastentheseatbelt,pull
downtherestraintbardown,andstarttheengine.
2.Presstheoperatebuttontoenablethehydraulics.
3.Removethebucketorattachmentfromthemounting
plate.
4.Parkthemachineonalevelsurface.
200929241
5.Fullyraisetheloaderarm.
RAPH14SSL0351BA2
4768391627/02/2015
