INTRODUCTION
RollOverProtectiveStructure(ROPS)certicationplate.
•
Frontedge(lower)insidecab.
931007505A3
Engineserialnumberplatelocation
•
OnthesideoftheExhaustGasRecirculation(EGR)
cooler.
•
Ontopofthevalvecover.
•
Theserialnumberisalsostampedontheenginefront
cover
231198664
Hydrostaticpump
•
Mechanical(Servo)hydrostaticpump
NOTE:Youmusttiltthecabforwardtoviewthehydro-
staticpump.Someitemsnotshownforclarity.
RAIL15SSL0133BA5
•
Electro-Hydraulic(EH)hydrostaticpump
NOTE:Youmusttiltthecabforwardtoviewthehydro-
staticpump.Someitemsnotshownforclarity.
RAIL15SSL0135BA6
