Casio CTK-50 Service Manual

— 14 —
Description of Capacitors
A general description of capacitors is shown in the following table.
The description consists of Type, Value, Rated Voltage and Tolerance.
When
y
ou need a capacitor, please find a subsutitution in
y
our countr
y
b
y
y
ourselves referrin
g
to the
description.
Ref. No of Capacitor Description
C101, C209, C211~C215, C217~C219, C222, C223, C301 Ceramic, 1.01 µF, 50 V, +/-20%
C102 Electrolytic, 10 µF, 16 V, +/-20%
C106, C112 Mylar, 0.047 µF, 50 V, +/-10%
C107, C108, C110, C111 Electrolytic, 47 µF, 10 V, +/-20%
C109 Electrolytic, 220 µF, 16 V, +/-20%
C201 Electrolytic, 2.2 µF, 50 V, +/-20%
C202 Semiconductive, 0.012 µF, 16 V, +/-10%
C203 Semiconductive, 0.027 µF, 16 V, +/-10%
C206, C207 Electrolytic, 330 µF, 6.3 V, +/-20%
C216 Electrolytic, 1 µF, 50 V, +/-20%
C302 Ceramic, 8.2 pF, 50 V, +/-10%
C303 Ceramic, 10 pF, 50 V, +/-5%
Description of Resistors
A general description of resistors is shown in the following table.
The description consists of Type, Value, Rated Wattage and Tolerance.
When you need a resistor, please find a subsutitution in your country by yourselves referring to the
description.
Note:
All resistors are carbon film, 1/5 watt, +/-5% otherwise specified.
Ref. No of Resistor Description
R101, R202 1 K
R102, R106, R301 1.2 K
R103, R108 3.3
R104, R107 390
R105 18 K
R109 820
R110, R115 560
R111 330
R112 220
R113, R208 100
R114 470
R116 15
R203, R204 3.9 K
R209~R226 2.2 K
R302 100 K
R303 150
