Casio CTK-7200 User Manual

Applying Effects to a Sound
E-30
■ DSP Effect Mode Configuration
The DSP effect mode is enabled while “DSP” is selected for the “Chorus/DSP”effect parameter. DSP and reverb can be used in the
DSP effect mode.
• Reverb
This type of effect simulates acoustic spaces. There are 10 different reverb effects, including room and hall.
•Chorus
This type of effect increases the depth of notes and applies vibrato to notes. There are five different chorus effects.
•DSP
This type of effect is inserted between the sound source and output. There are a total of 100 different DSP effects, including
distortion and modulation. You also can transfer DSP effects from a computer or create DSP data on the Digital Keyboard, and
store up to 100 user DSP effects in Digital Keyboard memory. For details, see “Creating a User DSP” (page E-33) and
“Connecting to a Computer” (page E-145).
DSP
DSP
DSP
Part Volume/Pan
Reverb Send
Volume/Pan
Reverb Send
Mic In
Inst In
Reverb
Master
Volume/Pan
DSP Reverb Send
DSP Volume/Pan
Tone Generator
Part A01-A16, B01-B16
Off
On
External Input
Output
Mono
Stereo
Off
On
Noise Gate
Auto Level
Control
CTK7300IN_e.book 30 ページ ２０１３年７月１９日 金曜日 午後１２時１分

Casio CTK-7200 Specifications

General

Control type	Buttons, Touch
MIDI-keyboard number of keys	61 keys
Display type	LED
Built-in display	Yes
Product color	Black, White
Sound effects	Chorus, Equalization, Flanger/Digital Signal Processing (DSP), Reverberation
Compatible products	GM Compatibility: Level1
Maximum polyphony (notes)	64
Music memory capacity (songs)	16
Power source type	Battery, DC
Interface	USB
Headphone outputs	1
Cables included	AC

Weight and Dimensions

Depth	384 mm
Width	948 mm
Height	122 mm
Weight	6700 g
