Casio HR-100TM Service Manual & Parts List

— 2 —
2. DISASSEMBLY
1. Remove the battery cover and the battery.
2. Remove two screws.
Hook positions
3. Remove eight hooks and remove the lower case.
4. Unsolder five lead wires.
Black
Orange
Red
Yellow
White
5. Unsolder the cable.

Casio HR-100TM Specifications

General

Type	Printing
Form factor	Desktop
Product color	Black
Housing material	Plastic
Digits	12 digits
Display tilting	No
Display number of lines	- lines

Weight and Dimensions

Depth	285 mm
Height	67 mm
Weight	165.5 g
Dimensions (WxDxH)	165.5 x 285 x 67 mm
