5. PARTS LIST: MODULE QW-3721
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ---------------------------------------- Very Important
B Rank ---------------------------------------- Important
C Rank ---------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name S
p
ecification A
pp
licable Q R
76408221 MODULE/WITH MOVEMENT QW-3721YC-02TK OCW-100TDJ-1A 1 A
OCW-110TDJ-1A
1 76408219 ANALOG BLOCK QW-3721MV-83TK QW-3721YC-02TK 1 A
2 10135068 BATTERY/STORAGE CTL1025 QW-3721YC-02TK 1 B
3 10172616 CONTACT/BATTERY (+) 3721 RJQ519936-001V02 QW-3721YC-02TK 1 C
4 10172619 CUSHION 3707-1 RJQ521249-002V01 QW-3721YC-02TK 1 C
5 10195754 CUSHION 3707-2 RJQ524197-001V03 QW-3721YC-02TK 1 C
6 10172615 HOLDER 3721 RJQ519902-001V01 QW-3721YC-02TK 1 C
7 10140782 LABEL 2815 RJQ517198-001V02 QW-3721YC-02TK 1 C
8 10008260 OSCILLATOR/CRYSTAL CFS-145JK07 QW-3721YC-02TK 1 B
9 76408256 PCB ASS'Y RJQ521705*001V01TK QW-3721YC-02TK 1 A
10 10137168 PLATE/TERMINAL 2787-1 RJQ515398-001V02 QW-3721YC-02TK 2 C
11 10137169 PLATE/TERMINAL 2787-2 RJQ515399-001V02 QW-3721YC-02TK 2 C
12 10123230 SCREW/FLAT2730 RJQ513792-001V01 QW-3721YC-02TK 4 B
13 71055275 SENSOR/TILT TS-2418-P QW-3721YC-02TK 1 B
14 10135066 SHEET/INSULATION 3315-3 RJQ515074-001V01 QW-3721YC-02TK 1 C
15 10172630 SHEET/INSULATION 3721 RJQ520957-001V01 QW-3721YC-02TK 1 C
16 72301000 SPRING/COIL 1604 Q458175A-1 QW-3721YC-02TK 1 B
17 10169534 SPRING/COIL 3707 RJQ521069-001V01 QW-3721YC-02TK 2 B
18 10169533 SPRING/LEAF 3707 RJQ520528-001V02 QW-3721YC-02TK 1 C
19 10006652 TAPE/ADHESIVE 2306 Q465964-1 QW-3721YC-02TK 1 C
20 10169526 TAPE/ADHESIVE 3707 RJQ521248-001V01 QW-3721YC-02TK 1 C
21 72270294 WASHER/745 Q436294A-1 QW-3721YC-02TK 1 C
22 10165772 WHEEL/HOUR 3721 RJQ519790-001V01 QW-3721YC-02TK 1 C
For the prices and minimum order/suppl
y
quantities of the above parts, refer to the Parts Price List P.P.L.-623.
Notes: Q - Used quantity
R - Rank
— 11 —
