5. PARTS LIST: QW-2424
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank --------------------------------------
-
Very Important
B Rank --------------------------------------
-
Important
C Rank --------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name S
p
ecification A
pp
licable Q R
MODULE/WITHOUT MOVEMENT QW-2424AT-02 MSG-130V-2V/MSG-130D-2V 1
MODULE/WITHOUT MOVEMENT QW-2424AT-03 MSG-130V-4V/MSG-130D-5V 1
MODULE/WITHOUT MOVEMENT QW-2424AT-05 MSG-130V-8V 1
< The module QW-2424 is "built-in t
yp
e" which is assembled directl
y
to the case,
therefore the module as the s
p
are
p
arts is not available. >
1 1006 0073 LCD S2424-01TTP QW-2424AT Common 1 A
2 7640 4807 PCB ASS'Y Q255299*1TK QW-2424AT Common 1 A
3 1001 0950 CAPACITOR/TRIMMER CTZ2E-30C-W2-P QW-2424AT Common 1 B
4 7110 0693 OSCILLATOR/CRYSTAL DT-26SJ QW-2424AT Common 1 B
5 1002 7903 CONTACT/BATTERY(-) Q39603B-1 QW-2424AT Common 1 C
6 7211 9631 CUSHION/506 Q49364-1 QW-2424AT Common 1 C
7 7211 0064 CUSHION/6 Q4914-1 QW-2424AT Common 1 C
8 1006 0069 HOUSING Q152181-1 QW-2424AT Common 1 C
9 1006 0074 INTERCONNECTOR 2424-1 Q468551-1 QW-2424AT Common 1 C
10 1006 0075 INTERCONNECTOR 2424-2 Q468552-1 QW-2424AT Common 1 C
11 1005 3573 LABEL Q468079-1 QW-2424AT Common 1 C
12 1006 0071 LIGHT GUIDE Q255212A-1 QW-2424AT Common 1 C
13 1006 0076 PANEL Q369962-2 QW-2424AT-02TK 1 C
14 1006 0077 PANEL Q369962-3 QW-2424AT-03TK 1 C
15 1006 0078 PANEL Q369962-4 QW-2424AT-05TK 1 C
16 7233 2629 SHEET/INSULATION Q461568-1 QW-2424AT Common 1 C
17 7230 0511 SPRING/COIL 1253-2 Q439219-1 QW-2424AT Common 1 B
18 7230 0980 SPRING/COIL 1514 Q456768-1 QW-2424AT Common 1 B
19 1006 0070 SUPPORTER/PCB ASS'Y Q152182-1 QW-2424AT Common 1 C
BATTERY/LITHIUM CR1620 QW-2424AT Common 1
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-576.
Notes: Q - Used quantity
R - Rank
