5. PARTS LIST : QW-2516
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ............................... Very Important
B Rank ............................... Important
C Rank ............................... Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Brister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication “GUIDEBOOK for spare parts supply”.
Notes: Q – Used quantity
R – Rank
Item Code No. Parts name Specification Applicable Q R
7640 5346 MODULE/WITHOUT MOVEMENT QW-2516AT-01TK BGR-250-2V 1 A
7640 5347 MODULE/WITHOUT MOVEMENT QW-2516AT-02TK BGR-250V-2V 1 A
7640 5348 MODULE/WITHOUT MOVEMENT QW-2516AT-03TK BGR-250-4AV 1 A
7640 5349 MODULE/WITHOUT MOVEMENT QW-2516AT-04TK BGR-250-4BV 1 A
7640 5350 MODULE/WITHOUT MOVEMENT QW-2516AT-05TK BGR-250-3V 1 A
7640 5351 MODULE/WITHOUT MOVEMENT QW-2516AT-06TK BGR-250V-6V 1 A
7640 5352 MODULE/WITHOUT MOVEMENT QW-2516AT-07TK BGR-250V-4V 1 A
7640 5353 MODULE/WITHOUT MOVEMENT QW-2516AT-08TK BGR-250V-3V 1 A
1 1007 6114 LCD S2516-01THP QW-2516AT Common 1 A
2a 7020 6090 EL YEL-1951-A-03 QW-2516AT-01TK 1 A
2b 1001 3459 EL YEL-1951-A-01 QW-2516AT-02TK 1 A
2c 7020 6092 EL YEL-1951-A-63 QW-2516AT-03TK/07TK 1 A
2d 7020 6144 EL YEL-1951-A-53 QW-2516AT-04TK 1 A
2e 1002 4508 EL YEL-1951-A-33 QW-2516AT-05TK/08TK 1 A
2f 1002 4507 EL YEL-1951-A-13 QW-2516AT-06TK 1 A
3 7640 5308 PCB ASS'Y Q255515*1TK QW-2516AT Common 1 A
4 1001 0950 CAPACITOR/TRIMMER CTZ2E-30C-W2-P QW-2516AT Common 1 B
5 7110 6316 OSCILLATOR/CRYSTAL DT-26S12 QW-2516AT Common 1 B
6 1002 7903 CONTACT/BATTERY(-) 156 Q39603B-1 QW-2516AT Common 1 C
7 7211 9631 CUSHION 506 Q49364-1 QW-2516AT Common 1 C
8 7211 0064 CUSHION 6 Q4914-1 QW-2516AT Common 1 C
9 7010 4674 INTERCONNECTOR Q463662-1 QW-2516AT Common 2 C
10 7424 3212 LABEL 1995 Q463482-1 QW-2516AT Common 1 C
11a 1007 6113 SPACER/PRINT Q469339A-1 QW-2516AT-01TK/05TK 1 C
11b 1007 6115 SPACER/PRINT Q469340A-1 QW-2516AT-02TK/06TK/08TK 1 C
11c 1007 6116 SPACER/PRINT Q469339A-2 QW-2516AT-03TK/04TK 1 C
11d 1007 6117 SPACER/PRINT Q469340A-2 QW-2516AT-07TK 1 C
12 7230 0378 SPRING/COIL 1160-1 Q436634-1 QW-2516AT Common 1 B
13 7230 0616 SPRING/COIL 1199-1 Q437728B-1 QW-2516AT Common 2 B
14 7230 0980 SPRING/COIL 1514 Q456768-1 QW-2516AT Common 1 B
7111 1059 BATTERY/LITHIUM CR1616 QW-2516AT Common 1
* For the price, new parts and minimum quantity of the above parts, please refer to the Parts Price List P.P.L.-580.
