4. PARTS LIST: MODULE QW-3042
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank --------------------------------------
Very Important
B Rank --------------------------------------
Important
C Rank --------------------------------------
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basi
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name S
ecification A
licable Q R
10229911 MODULE/WITHOUT MOVEMENT QW-3042YCSA-01 PRW-1100BJ 1 A
PRW-1100YTJ
10229914 MODULE/WITHOUT MOVEMENT QW-3042YCSA-02 PRW-1200J-1 1 A
PRW-1200TJ-7
1 10065657 BATTERY/STORAGE CTL1616 QW-3042YCSA Common 1 B
2 10083365 CONTACT/BATTERY(-) 1673 Q358740A-2 QW-3042YCSA Common 1 C
3 72180438 CUSHION 524 Q411459-1 QW-3042YCSA Common 2 C
4 10085146 CUSHION 2472-1 Q470055-1 QW-3042YCSA Common 1 C
5 10185435 EL YEL-2893-A-00 QW-3042YCSA Common 1 C
6 72311777 HOLDER 1381 Q456843-1 QW-3042YCSA Common 1 C
7 10174384 HOLDER/BATTERY 2154 Q254197-4V04 QW-3042YCSA Common 1 C
8 10185431 INTERCONNECTOR 2983-1 RJQ522026-001V01 QW-3042YCSA Common 2 A
9 10185432 INTERCONNECTOR 2983-2 RJQ522027-001V01 QW-3042YCSA Common 2 C
10 10065664 LABEL/ 2368 Q468543-1 QW-3042YCSA Common 1 C
11a 10226939 LCD (LOWER) K2893W-01EHP QW-3042YCSA-01 1 C
11b 10225744 LCD (LOWER) K2893W-02EHP QW-3042YCSA-02 1 C
12 10226936 LCD (UPPER) K2893S-01BTP QW-3042YCSA Common 1 A
13 10006374 SCREW 2306 Q464966-1 QW-3042YCSA Common 1 A
14 72019599 SPRING/COIL 967-1 Q430081-1 QW-3042YCSA Common 1 B
15 72301001 SPRING/COIL 967-1 Q430081A-2 QW-3042YCSA Common 2 B
16 72301037 SPRING/COIL 1583-1 Q462636-1 QW-3042YCSA Common 2 B
17 10185430 SPRING/COIL 2983-1 RJQ521949-001V01 QW-3042YCSA Common 2 B
For the
rices and minimum order/su
l
uantities of the above
arts, refer to the Parts Price List P.P.L.-633.
Notes: Q - Used quantity
R - Rank
— 5 —
