N Item Code No. Parts Name Specification Applicable Q R
R25
Chip resister(1.8kW) RES-01-1.8K Common
1
R28
Chip resister(47KW) RES-01-47K Common
1
C5
Chip capacitor(0.1mF) CAP-01-01 Common
1
C6~7, C35
Electrolytic capacitor(100mF) CAP-02-100-25 Common
3
C24
Chip capacitor(4700pF) CAP-01-4700 Common
1
C36
Tantalum capacitor(10mF) CAP-04-10-6.3 Common
1
PCB ASSEMBLY
N
4
6420 1880 Z876-1 ass'y C341328A*5 SF-5580E
1
B
N
4
6420 1890 Z876-1 ass'y C341328A*6 SF-5780E
1
B
N
4
6420 1900 Z876-1 ass'y C341328A*7 SF-5980E
1
B
5
6419 7320 Z876-2 ass'y C341329*1 Common
1
B
6
5610 9420 Heat seal HES-03-ZX876A Common
1
B
7
5610 9430 Heat seal HES-03-ZX876B Common
1
B
8
5610 9440 Heat seal HES-01-161055 Common
1
B
9
3502 2224 Heat seal HES-01-064065 Common
1
B
10
3335 6535 LCD LCD-03-ZX876 Common
1
B
11
3312 0057 EL LAM-03-ZX876 Common
1
B
COMPONENTS
12 6419 6180 Rubber key KEY-04-ZX876A-1 SF-5580E
1
C
12 6419 6190 Rubber key KEY-04-ZX876A-2 SF-5780E
1
C
12
6419 6200 Rubber key KEY-04-ZX876A-3 SF-5980E
1
C
13
6419 6210 Upper cabinet(display) HOU-04-ZX876-00 SF-5580E
1
C
13
6419 6220 Upper cabinet(display) HOU-04-ZX876-01 SF-5780E
1
C
13
6419 6230 Upper cabinet(display) HOU-04-ZX876-02 SF-5980E
1
C
14
6419 6240 Pad CON-05-507327 Common
2
X
15
6419 6250 Lower cabinet(keyboard) HOU-02-ZX876-00 SF-5580E
1
C
15
6419 6270 Lower cabinet(keyboard) HOU-02-ZX876-02 SF-5780E
1
C
15
6419 6290 Lower cabinet(keyboard) HOU-02-ZX876-04 SF-5980E
1
C
16
6419 6310 Upper cabinet(keyboard) HOU-01-ZX876-00 SF-5580E
1
C
16
6419 6320 Upper cabinet(keyboard) HOU-01-ZX876-01 SF-5780E
1
C
16
6419 6330 Upper cabinet(keyboard) HOU-01-ZX876-02 SF-5980E
1
C
17
6419 6340 Hinge rubber HIN-01-ZX-876 Common
1
X
18
6419 6350 Rubber key KEY-04-ZX876B-1 SF-5580E
1
C
18
6419 6360 Rubber key KEY-04-ZX876B-2 SF-5780E
1
C
18
6419 6370 Rubber key KEY-04-ZX876B-3 SF-5980E
1
C
19
6419 6400 Steel nut NUT-02-M1.7 Common
2
X
20
6419 6050 Battery spring BAC-01-ZX876- Common
1
X
21 6419 6060 Battery spring BAC-01-ZX876+/- Common
1
X
22 6419 6100 Battery spring BAC-01-ZX876+ Common
1
X
23 6419 6080 Rubber key KEY-03-U100 Common
1
C
24 6419 6120 Knob LOC-01-ZX876-00 SF-5580E
1
C
24 6419 6130 Knob LOC-01-ZX876-01 SF-5780E
1
C
24 6419 6140 Knob LOC-01-ZX876-02 SF-5980E
1
C
25 3122 3508 Buzzer BUZ-02-27 Common
1
X
N 26 3851 2068 Display plate LEN-01-ZX877-00 SF-5580E
1
B
N 26 3851 2069 Display plate LEN-01-ZX877-01 SF-5780E
1
B
N 26 3851 2070 Display plate LEN-01-ZX877-02 SF-5980E
1
B
27 6419 5720 Lower cabinet(display) HOU-03-ZX876-00 SF-5580E
1
C
27 6419 5730 Lower cabinet(display) HOU-03-ZX876-01 SF-5780E
1
C
27 6419 5740 Lower cabinet(display) HOU-03-ZX876-02 SF-5980E
1
C
Notes: N – New parts R – A : Essential
Q – Quantity used per unit B : Stock recommended
R – Rank C : Others
X : No stock recommended
— 28 —
