A/D PCB No. 2

FOB Japan

N Item Code No. Parts Name Specification M N.R.Yen R

C/I/N D Unit Price

Resistors

R606 2791 0343 Chip resistor ERJ-8GEYJ150V 1 0 20 5 C

N R606 2797 3794 Chip resistor ERJ-8GEYK3R9V 0 1 20 3 C

R607 2791 0343 Chip resistor ERJ-8GEYJ150V 1 0 20 5 C

N R607 2797 3794 Chip resistor ERJ-8GEYK3R9V 0 1 20 3 C

R610 2797 1841 Chip resistor ERJ-6GEYJ512V 1 0 20 3 C

R610 2797 1785 Chip resistor ERJ-6GEYJ242V 0 1 20 3 C

R611 2791 0815 Chip resistor ERJ-6GEYJ102V 1 0 20 5 C

R611 2797 2135 Chip resistor ERJ-6GEYJ132V 0 1 20 5 C

R615 2797 1785 Chip resistor ERJ-6GEYJ242V 1 1 20 2 C

R641 2791 0777 Chip resistor ERJ-6GEYJ104V 1 1 20 5 C

R645 2791 0696 Chip resistor ERJ-6GEYJ470V 1 1 20 4 C

R700 2791 1390 Chip resistor ERJ-6GEYJ473V 1 1 20 5 C

R704 2791 2141 Chip resistor ERJ-6GEYJ273V 1 1 20 4 C

R706 2791 0815 Chip resistor ERJ-6GEYJ102V 1 1 20 5 C

R707 2791 1650 Chip resistor ERJ-6GEYJ122V 1 1 20 3 C

R710 2797 2191 Chip resistor ERJ-6GEYK6R8V 1 1 20 3 C

R718 2792 0110 Chip jumper ERJ-6GEY0R00V 1 1 20 3 C

R725 2797 0245 Chip resistor ERJ-6GEYJ181V 1 1 20 2 C

R726 2797 2331 Chip resistor ERJ-6GEYF681V 1 1 20 4 C

R727 2797 3605 Chip resistor ERJ-6GEYF821V 1 1 20 3 C

R730 2791 2079 Chip resistor ERJ-6GEYJ562V 1 1 20 3 C

R733 2791 0777 Chip resistor ERJ-6GEYJ104V 1 1 20 5 C

R738 2791 2052 Chip resistor ERJ-6GEYJ224V 1 1 20 3 C

R740 2791 1633 Chip resistor ERJ-6GEYJ123V 1 1 20 3 C

R800 2791 1390 Chip resistor ERJ-6GEYJ473V 1 1 20 5 C

R803 2791 0815 Chip resistor ERJ-6GEYJ102V 1 1 20 5 C

R808 2791 0599 Chip resistor ERJ-6GEYJ822V 1 1 20 5 C

R809 2791 1595 Chip resistor ERJ-6GEYJ153V 1 1 20 4 C

R810 2791 1595 Chip resistor ERJ-6GEYJ153V 1 1 20 4 C

R814 2791 0750 Chip resistor ERJ-6GEYJ223V 1 1 20 6 C

R815 2791 2079 Chip resistor ERJ-6GEYJ562V 1 1 20 3 C

R816 2791 0750 Chip resistor ERJ-6GEYJ223V 1 1 20 6 C

R820 2797 1127 Chip resistor ERJ-6GEYK475V 1 1 20 3 C

N R824 2797 3801 Chip resistor RR1220P-153-D 1 1 20 3 C

N R825 2797 3808 Chip resistor RR1220R-114-D 1 1 20 3 C

R827 2791 0607 Chip resistor ERJ-6GEYJ333V 1 1 20 4 C

R830 2791 2052 Chip resistor ERJ-6GEYJ224V 1 1 20 3 C

R833 2791 0750 Chip resistor ERJ-6GEYJ223V 1 1 20 6 C

Switches

SW700 3412 1029 Switch SKHHAL 1 1 20 12 C

SW701 3412 1029 Switch SKHHAL 1 1 20 12 C

Variable Resistors

VR600 2765 0616 Volume RK09H11T-10KB 1 1 5 60 C

VR700 2775 1323 Semi-fixed resistor EVM-1SSW50B15 1 1 20 26 C

VR800 2765 1127 Volume RK09H11T-100KC 1 1 5 60 C

Notes: N – New parts

M – Minimum order/supply quantity

R – Rank

Quantity

— 21 —
