Casio TV-600C - Page 31

— 30 —
WAVEFORMS
63.5 µs 63.5 µs 63.5 µs
1.0 V0.9 V3.4 V4.0 V
2.8 V
2.6 V
800 mV
14 V
2.2 V
3.0 V
1.1 V
112 mV
1 Q200 Collector
4 IC300 Pin 23
7 IC300 Pin 4
0 Q111 Base A IC700 Pin 16 B IC700 Pin 14
8 IC300 Pin 1 9 Q111 Collector
5 IC300 Pins 10, 11, 12 6 IC300 Pin 5
0.24 µs 63.5 µs
63.5 µs
5.2 µs 130 ns 420 ns
63.5 µs 5.2 µs
63.5 µs
2 IC200 Pin 19 3 IC200 Pin 18
