6
3. Check the image
If step #1 does not work, then in test menu -> [1] -> [5] -> [4] (Scanned Image), count a bill and check the image.
If the image looks like [Fig. 3], the CIS should be replaced.
[Fig. 3]
If the image looks like [Fig. 4], the CIS or MAIN board is defective. (We assume the LED bar is working without
any problem). To identify the defective part, turn off the power and connect a new CIS to the MAIN board. Place
the CIS on a table or flat surface with a bill between the CIS and the table. Turn on the power and go into the
test menu again (Test menu -> [1] -> [5] -> [4]). Count a bill. The machine reads an image from the new CIS on
the table rather than the CIS in the machine. If the image looks like [Fig. 1] but with some strange but not all
black image of RGB and IR R then it means the MAIN board is OK. You should replace the CIS which is currently
installed in the machine. Otherwise if the image looks like [Fig. 4], you should replace the MAIN board.
[Fig. 4]
