ID ERRORS (by IR Light Source Problem) 5.3.
2.) Check the harness connectors
A.) Gently pull on each wire in the connector. All wires should be securely
clipped into the plastic connector
B.) If a wire connector is not clipped into the connector, then it looks like the
below picture.
GOOD BAD
[Fig. 5]
[Fig. 6]
48
