PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
39
SOLUTION TANK GROUP
GRUPE DEL DEPÓSITO DE DISOLUCIÓN
REF PART # DESCRIPTION QTY.
∇ 611633 ASM, COVER SOL. TANK BLUE 1
Y 1 603025 COVER , SOLUTION TANK BLUE 1
Y 2 611068 HINGE, COVER 1
Y 3 140706 RIVET, POP 1/8 7
4 606953 TANK, SOLUTION BLUE 1
5 607099 DSCREEN, SOLUTION FILL 1
6 3701.6 SCREW, #6 X 3/8 PAN SHTMTL 2
7 140032 WASHER, #6 FLAT 2
8 230665 BRACKET, CHARGER PLUG 1
9 140018 WASHER, #10 INT 2
10 140892 SCREW, 10--24 X 1/2 RNDPHL 2
11 2728.12 SCREW, 6--32 X 3/4 PANPHL 2
12 140019 WASHER, LOCK #6 EXT 2
13 605387 DCONNECTOR, RED 50A
WO/CONT.
1
14 230925 SUPPORT, RECOVERY TANK 1
15 611418 SLEEVE, 0.437D 0.315B 0.146 1
16 140027 WASHER, 5/16 FLAT 2
17 140015 WASHER, SPLITLOCK 0.31 1
18 140226 SCREW, HEX .31 --18 X 0.62 1
19 1012965 DCAP, PORT, SOLUTION FILL 1
20 01683 WASH ER, FLAT #10 1
21 1018155 SCREW, PAN #10--12 X 0.62 1
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
22 14884 FITTING, BRS STR BM08/PM06 2
23 700420 ASM., HOSE W/SOL. INDICATOR 1
24 607776 CLAMP, HO SE 2WIRE BLK 1
25 609376 DECAL, FS--2000 SIDE 2
26 120101 DECAL, CASTEX LOGO 1
27 150419 FITTING, 1/4MX3/8H ELB 90 BRS 2
28 607775 CLAMP, HO SE 2WIRE BLK 2
29 606240 DHOSE, 3/8IDX5/8ODX10.25 1
30 605324 GASKET, 1/2” CLOSED CELL 2
31 602927 TRAY, BATTERY 1
32 120589 DECAL, BATTERY PLACEMENT 1
33 602592 SUPPORT, TUBE BATTERY 1
34 130364 DCABLE, BATTERY #6BLKX15” 1
35 140835 SCREW, 10--24X3/8 PAN PHL 2
36 612764 SHIELD, LIGHT 1
37 130023 LIGHT, SAFETY 24VDC 14” 1
38 130869 BA TTERY, 12V 130AH (WET) 2
600594 BATTERY, 12V 130AH (DAMP) 2
39 603553 CHARGER, 24DC/12A 120V 1
130859 CHARGER, 24V 15AMP 230V/50HZ 1
40 700169 WIRE, #12X17 5/16 BLK 1
41 700168 WIRE, #12X12 3/8 RED 1
