PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
43
RECOVERY TANK GROUP
CONJUNTO DESPÓSITO RECUPERAR
REF PART # DESCRIPTION QTY.
∇ 1 701103 ASM, STAND PIPE W/NIPPLE 1
Y 2 606088 FITTING, 1--1/2” NIPPLE 1
3 101714 DGASKET, WASTE AIR CHAMBER 1
4 210240 NUT, 1--1/2 FPT FLNG METAL 1
5 180613 DFLOAT, SHUT--OFF (1) BALL 1
∇ 6 614148 ASM., TANK REC. BLUE 1
Y 7 613287 LABEL, WARNING DC 6” X 2.25” 1
Y8 120588 DECAL, BATTERY RECHARGING 1
∇ 9 100102 DASM., LID CLEAR W/STND HOLE 1
Y 10 100109 DLID, OUTER RING ONLY 1
Y 11 100105 DLID, CLEAR CENTER ONLY 1
12 140826 SCREW, #6 X 3/4 PHL SHTMTL 7
13 3701.6 SCREW, #6 X 3/8 PHL SHTMTL 1
14 230513 CHAIN 1
∇ 15 1010143 DASM., DRAIN HOSE 1
Y 16 1008639 DASM., CAP, DRAIN HOSE 1
Y 17 1008637 DO--RING 1
18 140308 CLAMP, HO SE 1
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
19 140259 SCREW, 1/4--20X5/8 2
20 140016 WASHER, 1/4 LOCK 2
21 140000 WASHER, 1/4 FLAT 2
22 140960 DCABLE, R EC. TANK SUPPORT 1
23 606923 STUD, 1/4--20 X 4.00 3
24 100038 DGASKET VAC MOTO R 5.7 1
∇ 25 605357 DMOTOR, VAC 24V 1/2 HP 1
Y 26 190163 DBRUSH, CARBON 2/PK 2
27 130133 TERMINAL, MALE .25 2
28 600009 DMUFFLER, VAC EXHAUST 1
29 130041 WIRE TIE, 11--1/2X.19 NY 1
30 41169 NUT, HEX LOCK .25--20 NY 3
31 140000 WASHER, 1/4 FLAT 3
32 605244 DHINGE, RECOVERY TANK 1
33 140000 WASHER, 1/4 FLAT 9
34 140052 WASHER, LOCK EXT 0.25 9
35 140885 SCREW, TRS 1/4--20 X 0.50 PHL 9
36 140300 CLAMP, INSULATED 1/2”ID 1
