PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
47
LEVER GROUP
CONJUNTO DE PALANCAS
REF PART # DESCRIPTION QTY.
1 230661 PLATE, LOCK CONTROL HOUSING 2
2 611979 WELDMENT, DRAIN HOSE
HANGER
1
3 200816 DGRIP, HANDLE 2
4 230719 HANDLE, SOLUTION VALVE 1
5 230735 BUSHING, SPACER 2
6 140060 W ASHER, .505 X .750 X .045 WAVE 1
7 140027 WASHER, 5/16 FLAT 4
8 140015 WASHER, 5/16 SPLITLOCK 4
9 140226 SCREW, 5/16--18X5/8 2
10 32520 NUT, .25--20 HEXJAM 1
11 140000 WASHER, 1/4 FLAT 4
12 140134 SLEEVE, 0.376D 0.253B 0.28L 2
13 140208 SCREW, HEX .25 --20 X 1.00 2
14 230728 HANDLE, SQUEEGEE LIFT 1
15 140221 SCREW, HEX .31--18X1.25 2
16 140016 WASHER, 1/4 LCK 2
17 140259 SCREW, 1/4--20X5/8 1
18 140510 NUT, 1/4 --20 HEXJAM 1
19 1015636 DCABLE, SQUEEGEE LIFT 1
20 230718 LEVER, SOLUTION VALVE 1
21 140951 SCREW, 10--24X7/16 2
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
22 140018 WASHER, LOCK INT #10 2
23 230712 PLATE, SQUEEGEE LOCK 1
24 140616 PIN, ROLL 1
25 230657 ARM, VALVE 1
26 606238 HOSE, 3/8IDX5/8ODX18 1
27 607776 CLAMP, HO SE 2WIRE BLK 1
28 140011 WASHER, 3/16 FLAT 4
29 140552 NUT, 10--24 NYLOCK 2
30 210259 DVALVE, BALL 3--WAY 1
31 140259 SCREW , HEX .25--20 X .62 2
32 27048 FITTING, BRS E90 04PM/04PF 2
33 140016 WASHER, 1/4 LOCK 2
34 600750 BRACKET, VALVE 1
35 140895 SCREW, 10--24X3/4 2
36 150206 FITTING, BRS PLUG 04PM HEX 1
37 605394 FITTING, BRS E45 BM06/PM04 1
38 150517 FITTING, BRS STR 04PM/08BM 1
39 606241 HOSE, 1/2ID X 6” 1
40 180629 FILTER, SCREEN 012 MESH 1
41 41169 NUT, HEX LOCK .25--20 NL 1
42 607775 CLAMP, HO SE 2WIRE BLK 2
