PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
51
BRUSH DRIVE GROUP
CONJUNTO IMPULSO DE CEPILLO
REF PART # DESCRIPTION QTY.
∇ 1 130491 DMOTOR, W/GEARBOX 24V IMP 1
Y 190970 DBRUSH, CARBON (SET OF 4) 4
Y 190741 DASM, BRUSH CARD 1
Y 630609 DGEAR BOX, IMPERIAL MOTOR 1
2 130192 TERMINAL ENDS 2
3 140431 SPRING, EXT 1.0 X 5.00 X 0.95 1
4 230871 BRACKET, MOTOR MOUNT 1
5 140823 SCREW, TRS 10--24 X 0.63 PHL 1
6 100091 BUMPER, RECESSED 1
7 140552 NUT, HEX 10--24 NY 1
8 607775 CLAMP, HOSE 2WIRE BLK 1
9 609924 HOSE, 3/8IDX5/8ODX19” CLEAR 1
10 140017 WASHER, LOCK SPLIT 0.38 4
11 140202 SCREW, HEX .31--16 X 1.00 4
12 606335 PLATE, DRIVE MOLDED 1
13 140197 SCREW, TRS 10--24X0.38 PHLSEM 4
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
14 230697 DSTOP, DRIVER RELEASE 1
15 230651 DCLAMP, BRUSH PLATE 1
16 140417 DCLIP, SPRING 1
17 25732 WASHER, 0.36B 1.25D .093 FLT 2
18 140015 WASHER, LOCK SPLIT 0.31 1
19 140219 SCREW, HEX .31 --18 X 1.00 1
20 140234 SCREW, HEX .50 --13 X 2.50 1
21 3148.816 WASHER, 0.52B 0.88D .06 1
22 140430 SPRING, HANDLE LOCK 1
23 140127 BEARING, THURST 2
24 140509 NUT, 1/2--13 HXJ M 3
25 140024 WASHER, LOCK 0.50 2
26 140139 SLEEVE, 0.625D 0.500B 0.25L 2
27 140045 WASHER, .51BX1.25DX.06 FLAT 4
28 140236 SCREW, HEX .50 --13 X 1.25 2
To Next Page
