PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
53
SKIRT GROUP
CONJUNTO JUEGO
REF PART # DESCRIPTION QTY.
∇ 606989 ASM, SKIRT 20” BLUE 1
Y 1 140799 DSCREW, TRS .31--18 X 1.50 PHL 2
Y 2 1014918 DWHEEL, RBR 3”X1” W/BUSHINGS 2
Y 3 140015 WASHER, 5/16 SPLITLOCK 4
Y 4 140027 WASHER, 5/16 FLAT 2
Y 5 230875 WEIGHT, 2X2.5X9.5 1
Y 6 609457 SKIRT, HSG. 20” BLUE 1
Y 7 605958 DGUARD, SPLASH 2
Y 8 605959 STRAP, SPLASH GUARD 2
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
Y 9 605975 SCREW, TRS 10--24X0.50 PHL SEM 16
Y 10 606986 DCASTER, SWIVEL 3”X1.25” 2
Y 11 140000 WASHER, 1/4 FLAT 8
Y 12 140016 WASHER, LOCK 0.25 8
Y 13 140259 SCREW, HEX .25--20 X .62 8
Y 14 140220 SCREW , 5/16--18X2--1/2 TAP 2
15 140027 WASHER, FLAT 0.31 4
16 140015 WASHER, LOCK SPLT 0.31 4
17 140216 SCREW, HEX .31 --18 X 1.50 4
