PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
55
CURVED SQUEEGEE ASSEMBLY
CONJUNTO PALETA ENCORUADO
REF PART # DESCRIPTION QTY.
1 230731 PIVOT, SQUEEGEE MOU NT 1
2 140045 W ASHER, 0.51B 1.25D .06 FLAT 4
3 140024 WASHER, LOCK 0.50 2
4 140237 SCREW, HEX .50--13 X 1.00 2
5 1015636 DCABLE, SQUEEGEE LIFT 1
6 140139 SLEEVE, 0.625D 0.50B 0.25L 2
7 140524 NUT, 1/4--20 KEP 2
8 140433 SPRING, EXT .50 X 3.00 2
9 160617 DHOSE, VAC 1 1/2X24” W/CUFFS 1
10 230730.BK BRACKET, SQUEEGEE MOUNT 1
∇ 603261 DASM., SQUEEGEE CURVED 1
Y 11 1011094 DKNOB, RND 1.50 DIA 5 EAR 2
Y 12 603260 DGASKET, SQUEEGEE CURVED 1
Y 13 140226 SCREW, HEX .31--18 X 0.62 2
Y 14 140015 WASHER, LOCK SPLIT 0.31 2
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
Y 15 700844 DASM, SQ UEEGEE ROLLER 2
Y 16 140799 SCREW , TRS .31--18 X 1.50 2
Y 17 1014918 DWHEEL, RBR 3”X1” W/BUSHINGS 2
Y 18 602959 WELDMENT, SQUEEGEE 20” 1
Y 19 605975 SCREW, TRS 10--24X.50 PHL SEM 18
Y 20 602964 DPLATE, SQU EEGEE RETAINING 2
Y 21 603659 DBLADE, URETHANE (STANDARD) 2
Y 22 140221 SCREW, HEX .31--18 X 1.25 2
∇ 611453 DKIT, SQ UEEGEE LINATEX
(OPTIONAL)
1
Y 607465 DBLADE, LINATEX REAR ONLY
(OPTIONAL)
1
Y 61 1449 DBLADE, LINATEX FRONT ONLY
(OPTIONAL)
1
606676 DBLADE, GUM RUBBER REAR
ONLY (OPTIONAL)
1
