3. Use the 13mm wrench to secure the
spindle by sliding the wrench over
the spindle flats until it is fully
engaged. (figure 9c)
4. Next, while holding the spindle securely
with the 13mm wrench, use the 22mm
collet wrench to loosen the collet chuck
assembly in a counter-clockwise
direction.(figure 9d) With the collet chuck
assembly loosened, pull down on the
pocket cutting lever enough so that you
can remove and replace the router bit.
CAUTION- Router bits are extremely sharp and if handled improperly may
result in personal injury.
