TSM-35 Screw Pocket Machine Troubleshooting
o If you can stop the carriage:
Listen / feel for air leaks at the muffler breather on the drill
solenoid
• If there is a constant leak when trying to stop the
carriage, replace the drill cylinder (P35125
)
• If there is a constant leak when the machine is at
rest, change the drill solenoid (P49410
)
Listen / feel for air leaks at the super quick exhaust (SQE)
(P10320
) on the drill feed rate assembly.
• If there is a constant leak without overriding the
solenoid, replace the drill cylinder (P35125
)
• If there is a constant leak when the drill solenoid is
overridden, replace the SQE (P10320
)
If there are no air leaks, replace the drill solenoid (P49410)
