(Table 16, contd)
GENERATOR START-UP CHECKLIST
Main Rotor
Exciter Stator
Exciter Rotor
PMG Stator
Regulator Voltage Amps Comments
No Load F1 to F2 DC
20 to 22 AC
20 to 24 AC
22 to 24 AC
24 to 30 (SE only) AC
26 to 28 (PM only) AC
26 to 30 (PM only) AC
28 to 30 (PM only) AC
Full Load Generator Excitation Name
Plate Information:
DC Compare with F1 to F2
F1 to F2 DC
20 to 22 AC
20 to 24 AC
22 to 24 AC
24 to 30 (SE only) AC
26 to 28 (PM only) AC
26 to 30 (PM only) AC
28 to 30 (PM only) AC
Table 17
GENERATOR START-UP CHECKLIST (CONT.)
ELECTRICAL Yes No Comments
Unit properly grounded
Check diodes
Over current protection
Over voltage protection
Check for loose wiring
Adjust voltage
Adjust frequency
MECHANICAL Data Comments
Bearing temperature readings at full load Front __________ Rear ___________
Stator temperature readings at full load A0 _______ B0 _______ C0 _______
(continued)
102
SEBU7125-13
Maintenance Section
Generator Start-up Checklist
