Technical CATERPILLAR – 1000 kVA Page
22
Description UTILITY POWER MODULE
Revision 1.0 1 May 2006
4. EMCP 3.3 GENERATOR SET CONTROLLER
4.1. EMCP 3.3 General Description
The Caterpillar
®
EMCP 3.3 includes fully featured power metering, protective relaying and
engine and generator control and monitoring. Engine and generator controls, diagnostics,
and operating information are accessible via the control panel keypads; diagnostics from the
J1939 Network modules can be viewed and reset through the EMCP 3.3. The EMCP 3.3
features a graphical display with a white backlight visible in all types of light as well as an
advanced engine monitoring system.
4.2. EMCP 3.3 Operator Interface
• Graphical display with positive image, transflective LCD, adjustable white
backlight/contrast.
• Two LED status indicators (1 red, 1 amber).
• Three Engine Control Keys and Status Indicators (Run/Auto/Stop).
• Lamp Test Key.
• Alarm Acknowledgement Key.
• Display Navigation Keys.
• Two Shortcut Keys: Engine Operating Parameters and Generator
Operating Parameters.
4.3. EMCP 3.3 Features & Benefits
• A 64 x 240 pixel, 28 mm x 100 mm, white backlit graphical display denotes text
alarm/event descriptions and is visible in all lighting conditions.
• Textual display with multiple language capability, including character languages such
as Arabic, Chinese, and Japanese.
• Advanced engine monitoring is available on systems with an electronic engine control
module.
• Integration with the CDVR provides enhanced system performance.
• Ability to view and reset diagnostics on J1939 Network modules via the control panel
removes the need for a separate service tool for troubleshooting.
• Fully featured power metering, protective relaying, engine and generator parameter
viewing, and expanded AC metering are all integrated into this controller.
• Real-time clock allows for date and time stamping of diagnostics and events in the
control’s logs as well as service maintenance reminders based on engine operating
hours or calendar days.
• Customer programmable protective relaying, available as alarm and shutdown,
protects against undervoltage, overvoltage, underfrequency, overfrequency,
overcurrent, and reverse power.
• Digital, 32-bit microprocessor-based system eliminates the need for multiple switches,
meters, transducers, relays, and sending units, which translates to less wiring and
fewer opportunities for mechanical failures.
• Expanded remote customer communications are supported by MODBUS RTU (1/2
