Technical CATERPILLAR – 1000 kVA Page
46
Description UTILITY POWER MODULE
Revision 1.0 1 May 2006
The 3L-0284 generator set package test will be as follows:
Results at full load reported are: engine RPM, frequency, average voltage, line-to-line
voltages for all three phases, average current, line-to-line current for all three phases, and
observed power (all at 0.8 power factor). Engine RPM, average voltage and line-to-line
voltages for all three phases are reported at no-load.
This will be followed by a transient response test where the following load steps (at 0.8 pf)
will be applied: ISO load steps for 50hz operation: 0-41, 41-60, 60-92, 92-100.
7.3. Documentation
Caterpillar
®
Utility Power Module documentation includes:
• As built electrical schematics
• Container package drawings
• Caterpillar sheets
• Repair parts lists.
Reference: DCQ123-9
