Any of these actions may cause serious electrical damage and/or a fire.
CAUTION: TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
• This charger is not designed for use with every make, manufacture or model of engine.
Use only
with 12 volt systems.
• NEVER ATTEMPT CHARGE A FROZEN BATTERY.
• Do not charge the battery while the engine is operating.
• Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to persons.
• When working with lead acid batteries, always make sure immediate assistance is available in case of
accident or emergency.
• Always have protective eyewear when using this product: contact with battery acid may cause
blindness and/or severe burns. Be aware of first aid procedures in case of accidental contact with
battery acid.
• Have plenty of fresh water and soap nearby in case battery acid contacts skin.
• If battery acid contacts skin or clothing, wash immediately with soap and water for at least 10 minutes
and get medical attention immediately.
• Never smoke or allow a spark or flame in vicinity of vehicle battery, engine or battery maintainer.
• Remove personal metal items such as rings, bracelets, necklaces and watches when working with a
lead acid battery. A lead acid battery can produce a short circuit current high enough to weld a ring, or
similar metal object, to skin causing a severe burn.
• Never allow battery acid to come in contact with this unit.
• Do not operate this unit in a closed area or restrict ventilation in any way.
• Always turn the battery charger off by unplugging it when not in use.
• Do not open the BATTERY CHARGER — there are no user-serviceable parts inside. Opening the battery
charger will void manufacturer’s warranty.
• Operate battery charger only as described in this Instruction Manual.
• Check battery charger and components periodically for wear and tear. Return to manufacturer for
replacement of worn or defective parts immediately.
Connection Precautions
• Connect and disconnect output clamps, terminal rings or vehicle accessory plug only after removing
AC cord from electric outlet.
• Never allow clamps or terminal rings to touch each other.
• Attach clamps only as indicated in “Charging Using the Supplied Battery Clips.”
First Aid
•
SKIN:
If battery acid comes in contact with skin, rinse immediately with water, then wash thoroughly
with soap and water. If redness, pain, or irritation occurs, seek immediate medical attention.
•
EYES:
If battery acid comes in contact with eyes, flush eyes immediately, for a minimum of 15
minutes and seek immediate medical attention.
CAUTION: TO REDUCE THE RISK OF PROPERTY DAMAGE WHEN USING THE UNIT IN WET
ENVIRONMENTS:
The housing of this unit is rated to IP67 dust-proof and waterproof standards. However, it is
recommended that you observe the following:
• Never submerge the unit in water deeper than 1 meter, for time longer than 30 minutes and/or in
temperatures other than between 41ºF and 104ºF (5ºC and 40ºC), or the unit could sustain permanent
damage.
• Never submerge the unit in water unless the bushing (insulation) of the AC or DC cord is intact.
• Do not allow plug, terminal rings or clamps to be exposed to the elements for long periods of time;
and never submerge them.
• Read and Understand This Instruction Manual Before Using This Unit.
SAVE THESE INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
Follow these instructions
and those published by the manufacturer of any vehicle and battery you intend to use with this battery
charger. Review cautionary markings on the battery charger and engine.
INTRODUCTION
Congratulations on purchasing your new
Cat
®
4 Amp Waterproof Battery Charger/Maintainer
.
Read
this Instruction Manual and follow the instructions carefully before using your new battery
charger.
5
FEATURES
120 VOLT
AC PLUG
DOUBLE BARREL CHARGER
CONNECTOR (CONNECTS TO
CLAMPS, BATTERY TERMINAL
RINGS OR VEHICLE
ADAPTER PLUG)
POWER LED
REVERSE
POLARITY/FAULT
LED
BATTERY
CHARGING LED
CHARGING
COMPLETE LED
BATTERY
CLIPS
DC ACCESSORY
PLUG
BATTERY TERMINAL
RINGS
OPERATING INSTRUCTIONS
Preparing to Charge
1. Remove battery completely from boat/airplane or any confined area before charging.
2. If it is necessary to remove battery from vehicle to charge, or to clean terminals, always remove
grounded terminal from battery first. Make sure all accessories in the vehicle are off, so as not to
cause an arc.
3. Clean battery terminals, taking care to avoid getting corrosive material in eyes.
