Application and Installation Guide EMCP 4 SCADA Data Links
©2013 Caterpillar
All rights reserved. Page 62
Parameter Name R/W
Holding
Register
Ct
Data Interpretation
Sec
Lvl
4.2 4.3 4.4
Scaling
(Resolution)
Offset Limits (Range)
Service Maintenance
Interval Hours Remaining
R 210 0x00D1 1 1 hr / bit
-32127
hr
-32127 to 32128 hr 0 ● ● ●
Service Maintenance
Interval Days Remaining
R 212 0x00D3 1 1 day / bit
-32127
days
-32127 to 32128 days 0 ● ● ●
Number of Crank Attempts R 213 0x00D4 2 1 / bit 0 0 to 4211081215 0 ● ● ●
Number of Successful Starts R 215 0x00D6 2 1 / bit 0 0 to 4211081215 0 ● ● ●
Engine Oil Pressure from
Data Link
R 217 0x00D8 1 0.125 kPa / bit 0 kPa 0 to 8031.875 kPa 0 ● ● ●
Engine Coolant Temperature
from Data Link
R 219 0x00DA 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #1 Exhaust Port
Temperature from Data Link
R 221
0x00D
C
1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #2 Exhaust Port
Temperature from Data Link
R 222
0x00D
D
1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #3 Exhaust Port
Temperature from Data Link
R 223 0x00DE 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #4 Exhaust Port
Temperature from Data Link
R 224 0x00DF 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #5 Exhaust Port
Temperature from Data Link
R 225 0x00E0 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #6 Exhaust Port
Temperature from Data Link
R 226 0x00E1 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #7 Exhaust Port
Temperature from Data Link
R 227 0x00E2 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #8 Exhaust Port
Temperature from Data Link
R 228 0x00E3 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #9 Exhaust Port
Temperature from Data Link
R 229 0x00E4 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #10 Exhaust Port
Temperature from Data Link
R 230 0x00E5 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #11 Exhaust Port
Temperature from Data Link
R 231 0x00E6 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #12 Exhaust Port
Temperature from Data Link
R 232 0x00E7 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #13 Exhaust Port
Temperature from Data Link
R 233 0x00E8 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #14 Exhaust Port
Temperature from Data Link
R 234 0x00E9 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #15 Exhaust Port
Temperature from Data Link
R 235 0x00EA 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #16 Exhaust Port
Temperature from Data Link
R 236 0x00EB 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #17 Exhaust Port
Temperature from Data Link
R 237 0x00EC 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #18 Exhaust Port
Temperature from Data Link
R 238 0x00ED 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #19 Exhaust Port
Temperature from Data Link
R 239 0x00EE 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Cylinder #20 Exhaust Port
Temperature from Data Link
R 240 0x00EF 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Exhaust Manifold #1 (Left)
Temperature from Data Link
R 241 0x00F0 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
