Application and Installation Guide EMCP 4 SCADA Data Links
©2013 Caterpillar
All rights reserved. Page 63
Parameter Name R/W
Holding
Register
Ct
Data Interpretation
Sec
Lvl
4.2 4.3 4.4
Scaling
(Resolution)
Offset Limits (Range)
Exhaust Manifold #2 (Right)
Temperature from Data Link
R 242 0x00F1 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Intake Manifold #1
Temperature from Data Link
R 243 0x00F2 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Intake Manifold #2
Temperature from Data Link
R 244 0x00F3 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Engine Oil Temperature
from Data Link
R 245 0x00F4 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Engine Fuel Temperature
from Data Link
R 246 0x00F5 1 0.03125 C / bit -273 C -273 to 1735 C 0 ● ● ●
Fuel Pressure from Data
Link
R 247 0x00F6 1 0.125 kPa / bit 0 kPa 0 to 8031.875 kPa 0 ● ● ●
Crankcase Pressure from
Data Link
R 248 0x00F7 1 1 / 128 kPa / bit
-250
kPa
-250 to 251.99 kPa 0 ● ● ●
Boost Pressure from Data
Link
R 249 0x00F8 1 0.125 kPa / bit 0 kPa 0 to 8031.875 kPa 0 ● ● ●
Oil Filter Differential
Pressure from Data Link
R 251 0x00FA 1 0.5 kPa / bit 0 kPa 0 to 125 kPa 0 ● ● ●
Fuel Filter Differential
Pressure from Data Link
R 252 0x00FB 1 0.125 kPa / bit 0 kPa 0 to 8031.875 kPa 0 ● ● ●
Air Filter 1 Differential
Pressure from Data Link
R 253 0x00FC 1 1 / 128 kPa / bit
-250
kPa
-250 to 251.99 kPa 0 ● ● ●
Total Fuel Consumption
from Data Link
R 254 0x00FD 2 0.5 L / bit 0 L 0 to 2105540607.5 L 0 ● ● ●
Instantaneous Fuel
Consumption from Data Link
R 256 0x00FF 1 0.05 L/h per bit 0 L/h 0 to 3212.75 L/h 0 ● ● ●
Atmospheric Pressure from
Data Link
R 257 0x0100 1 0.125 kPa / bit 0 kPa 0 to 8031.875 kPa 0 ● ● ●
Fuel Level R 258 0x0101 1 0.0078125 % / bit -251 % -251 to 250.99 % 0 ● ● ●
Net Battery Current from
Data Link
R 259 0x0102 1 1 A / bit -125 A -125 to 125 A 0 ● ● ●
Service Maintenance
Interval Weeks Remaining
R 299 0x012A 1 1 week / bit
-125
weeks
-125 to 125 weeks 0 ● ● ●
Bypass Cooldown (NOTE 1) W 300 0x012B 1
00 = FALSE
01 = TRUE
0 ● ● ●
Engine Control Switch
Position
R 301 0x012C 1
0 = STOP
1 = AUTO
2 = RUN
0 ● ● ●
Engine Control Switch
Command (NOTE 1)
W 302 0x012D 1
0 = STOP
1 = AUTO
2 = RUN
0 ● ● ●
Lamp Test Command
(NOTE 1)
W 303 0x012E 1
00 = FALSE
01 = TRUE
0 ● ● ●
Acknowledge All Events
Command (NOTE 1)
W 304 0x012F 1
00 = FALSE
01 = TRUE
0 ● ● ●
Auto Start/Stop Fuel Control
Enabled
R 307 0x0132 1
00 = FALSE
01 = TRUE
0 ● ● ●
Key Press (NOTE 1) W 310 0x0135 1
0 = FALSE
1 = TRUE
SCR System Check
Required Status
R 319 0x013E 1
0 = FALSE
1 = TRUE
2 = ERROR
3 = DISABLED OR NOT AVAILABLE
0 ● ● ●
