OPERATION
The purpose of the inching pedal is to provide
precise lift truck inching control at very slow
travel speed and high engine rpm. You can
move your truck slowly while maintaining the
engine speed by varying the position of the
inching pedal. Use this pedal when approach-
ing the load and when loading and unloading.
1. Stop ahead of the load platform, lock the
parking brake lever, set the direction lever
to NEUTRAL, place the mast vertically,
and raise the fork to the height of the pallet
insertion openings.
2. Depress the inching pedal all the way,
move the direction lever to FORWARD,
and release the parking brake.
3. Gently depress the accelerator pedal.
4. When the left foot is slowly taken off the
inching pedal, the fork lift will advance
slowly.
5. Insert the fork slowly, taking care it does
not hit the pallet.
6. Stop after inserting the fork until the root
of the fork comes into light contact with
the pallet.
• Inching
DO NOT “ride” the inching pedal during
traveling. This produces a partly disengaged
condition that will result in premature clutch
plate wear.
100747
100748A 100749A
CAUTION
!
