PRODUCE LVSTRUCTURAL BRIEF INTRODUCTION
1.Cover
2.Stator shell
3.Cover
4.Gearbox
5.Water seal
6.Spindle(a: Beijing thread; b, 1-1/4“
-3UNC; C: 1-1/4”-7UNC, d: 1-1/4”
-7UNC G/1/2)
7.Core bit
8.Motor switch
9.Rack
10.Column
11.Handle
12.Rocking bar
13.Fitting
14.Lifter
15.Lifting cover
16.Hose tap
17.Base (a. normal stand b.angle
adjustable bracket)
18.Plug (A.CN B.GB C.EP D.US)
