GENERALINFORMATION
TheCB516/24Vswitch-modebatterychargerhasbeenexpresslydesignedforthecaravanningand
boatingsectorandcanautomaticallycharge24Vd.c.leadbatteries.
1) withmaximumcurrentuntiltheend-chargevoltageisreached:
Thebatterychargerisprotectedagainstovertemperatureandthe24Vd.c.outputsareprotectedagainst
shortcircuitandpolarityinversion.
Thechargingsystemiscarriedoutin4stages:
2)whenthe thresholdisreachedthechargercontinuestooperatefor90minutes(lead
batteries)or8hours(gelbatteries)withconstantvoltage.
3) voltageholding27.6Vd.c.(gelbatteries)or27.0Vd.c.(leadbatteries)
4) After10hours,thebatterychargerreachesthe modeandbeginstooperateagainonly
whenthebatteryvoltageislowerthan26Vd.c.
Thehighfrequencyswitchingtechnologyallowstohavehighperformanceswithsmalldimensionsand
limitedweight.
batterycharging
Note:theend-chargevoltageisreachedonlyifthebatteryisefficient.
end-charge
Constant
stand-by
GB
CONNECTIONS
-Technicaldataareindicatedalsointhelabelinsidethecover-
ENGLISH
Pb/Gel
Battery
230Va.c.On/Off
Fuse230Va.c.
F2-F2A
N B : F A C T O R Y S E T T I N G O F T H E S E L E C T O R I S O N " P b " ( A C I D )
24Vd.c.BATTERY
BLACK
1) +24Vd.c.supply(BLEU)
2) -24Vd.c.supply(BLACK)
15
15
Fuse24Vd.c.
F1-F15A
