Schuko plug
230V
GB
7
CONNECTIONS
230V On/Off
Fuse 230V
F2 - T 3.15A
L=3mt
B
C
A
4
2 1
3
- -Technical data are indicated also on the label inside the cover
-12V
Net signal (+12V )
SIGNAL
3
4
CONNECTION BATTERY TEMPERATURE SENSOR (optional)
BLACK
1
-12V supply
12V CONNECTION
2
+12V supply
12V CONNECTION
+12V
30AF1
Fuse 12V
Temperature sensor (mod. “CTCB”) , where it
cannot be affected by other heat sources
When connected, the charging voltage is adapted according to the temperature
measured by the sensor.
to be placed close to the battery
Temperature sensor
mod."CTCB"
(optional)
to be placed close to the battery
