Troubleshooting Chart.
TROUBLESHOOTING CARBON MONOXIDE GAS ALARM
MODEL 3400 for RESIDENTIAL USE
Description
Green Light
Red Light Orange Sounder
Resolution
Normal
Operation
On
On
On
Off
Off
Off
Off
Off
Off
Off
Off
Flashing
No Sound.
Four Beeps
then a pause,
every 5
seconds.
Follow "What
you should know
if the CO alarm
sounds"section.
You only have
protection if the
unit is powered.
Off
Beep once
every 5
seconds.
Four beeps.
Call CCI
Controls.
Unit ready when
green LED
turns back on.
Turns on, then
turns back off.
Flashes four
times,
then stops.
Dims off, then
turns back on.
CO Gas
Detected
No Power
Fault
Condtion
Test Mode
What You Should Know About
Interaction With Other Products.
Never ignore a CO alarm. A true alarm is an indication of
potentially dangerous levels of carbon monoxide. This CO
alarm is designed to provide an early warning signal to alert you
to the presence of CO gas at the gas sensor. The alarm is
designed to sound before most people will experience danger-
ous symptoms of CO poisoning. If you have special health
conditions or medical problems, you should consider purchas-
ing other warning devices which provide audible and visual
signals for CO concentrations under 30 parts per million
(PPM).
In concentrated amounts, some common household products
may cause the alarm to sound. These items could include
alcohol, liquor, kerosene, gasoline, deodorants, colognes,
household cleaning products and aerosols. When this occurs,
air out the residence and the CO alarm with fresh air.
Sometimes the CO alarm can sound because of:
Temperature inversions which can trap exhaust gases
near the ground;
Obstructed vent pipes or unvented fuel burning appli-
ances;
Vent pipe connections vibrating loose from clothes
dryers,heaters or furnaces;
High outside wind causing CO to back up in the air
vent pipes;
Negative air pressure resulting from the use of exhaust
fans;
Simultaneous use of several fuel burning appliances
competing for internal air;
Fuel-powered vehicles or equipment idling nearby.
Important Notes:
Some products may prevent or delay your CO gas alarm
from detecting carbon monoxide. Therefore, your CO gas
alarm should not be:
Installed too low where items such as water and other
household chemicals can pollute the sensor;
Covered, obstucted, or painted;
Exposed to sulfur products or powders of any kind.
Technical Information:
Sensor Level 70 ppm or more of carbon monoxide gas
and before 10% carboxyhemoglobin
(COHb) exposure level.
Operating Green LED Illuminated.
Alarm Alarm will sound and Red LED will flash.
Fault Condition Orange LED Illuminated. Alarm will beep
every 5 seconds.
Low Voltage Condition Orange LED illuminated. Alarm will beep
every 60 seconds.
Audio Alarm 85dB at 10 Feet
Supply Voltage 120 Volt 60Hz AC adapter.
Current Draw 50 milliamps maximum
Dimensions 3
1/2
x7x1
5/8
inches 8.89x17.78x4.12 cm
Storage Temperature -40° F to 158° F -40° C to 70° C
Operating Temperature 32° F to 120° F 0° C to 49° C
LIMITED WARRANTY
CCI Controls warrants the equipment described hereon to be free from defects in material
and workmanship under normal use and service when installed and used in accordance
with all applicable state and local laws and regulations. CCI Controls sole obligation
hereunder shall be limited to repairing or replacing the component or components shown
to have been defective at time of shipment or to have become inoperative within the term
of the warranty. This warranty does not cover transportation to and from the service
locations, loss of time, inconvenience, commercial loss, loss of use, incidental changes,
or other consequential damages. This warranty shall be for the term of two years from
the date of the first sale by the dealer to the consumer. The consumer may be asked
to produce the original sales contract or receipt to identify the date of purchase.
This CO gas alarm contains no user-serviceable parts. If you have questions as to
servicing this alarm, contact CCI Controls. This warranty is voided if the alarm's casing
is opened.
Relay Contact Rating 2 Amps resistive
Call (800) 521-5228
If you have any questions about your
Carbon Monoxide Gas Alarm
5052 Cecelia St South Gate, CA 90280
Phone (323) 560-6060 FAX (323) 560-1136
www.ccicontrols.com
THIS PRODUCT IS MADE IN THE UNITED STATES.
The alarm may no longer accurately detect carbon
monoxide after the replacement date listed on the front
cover. You should immediately replace the alarm when
the replacement date is reached.
