13
•Firmly pull the condenser using
the handle to remove it from the
dryer.
•Rinse between the plates under
a tap or with running water to
remove any lint or flu.
•Carefully shake any excess water
from the condenser.
•Whilst the condenser is removed,
clean as much flu as possible
from inside the ducting by
reaching a hand into the machine.
In particular, keep the passage
from the fan clear (on the right
hand side of the condenser duct).
•Carefully push the condenser
back into its housing, until it is
pushed fully home and a “click” is heard.
Please note:
All lint and flu must be removed from around the seals before
replacing the condenser into its housing or water may leak.
The dryer may leak if the condenser is not correctly re-installed.
The condenser will discolour through use. This is normal and does
not constitute a fault.
fig. 2
