CDA FF820 User Manual

9
fig. 7
Reversing the door
6. Remove the lower hinge and reposition the lower hinge pin as
shown in figure 5.
7. Reposition the lower hinge on the opposite side as shown in fig 7.
8. Reverse the upper hinge pin as shown in fig 6.
9. Locate the door on the lower hinge pin, then locate the upper hinge
pin in the door.
10. Slot the upper hinge into the locating screw on the appliance and
then secure with the two screws removed in step 3.
11. Carefully refit the control panel, ensuring there are no trapped
wires.
11. Replace the cover caps and hinge cover plates.
fig. 5
fig. 6
Lower hinge
fig. 8
fig. 9
