19
6. Pop out the cover caps on the opposite side and use them to
cover the screw holes on the original side.
7. Fit the alternative upper hinge on the opposite side.
8. Rotate the door 180º and relocate it on the top hinge.
9. Refit the modified lower hinge into the door and secure it to the
appliance body using the screws removed in step 1.
10. Refit both ventilation trims.
Please note:
Keep the spare hinge plate(s) to be able to reverse the door back
again.
Door reversal diagram index
1 - Rear ventilation trim screw access and screw
2 - Rear ventilation trim
3 - Front ventilation trim screw
4 - Front ventilation trim
5 - Lower hinge
6 - Lower hinge fixing screw
7 - Short hinge pin
8 - Main hinge pin
9 - Hinge bracket
10 - Upper hinge
11 - Upper hinge fixing screw
12 - Replacement top hinge
