CDA RC9301 User Manual

19
Burners
They can be removed and washed only with
soapy water.
Detergents can be used but must not be
abrasive or corrosive.
Do not use abrasive sponges or pads.
Do not put in dishwasher.
After each cleaning, make sure that the
burner-caps, as well as the burners, have
been well wiped off and CORRECTLY
POSITIONED.
It is essential to check that the burner
flame distributor F and the cap C has been
correctly positioned (see fig. 17) - failure to
do so can cause serious problems.
Check that the electrode “S” (figs. 17-18) is
always clean to ensure trouble-free spark-
ing.
Check that the probe “T” (figs. 17-18) next
to each burner is always clean to ensure
correct operation of the safety valves.
Note:
The electrode “S” must be very carefully cleaned.
To avoid damage to the electric ignition do not use it when the burners are not
in place.
Triple ring burner
The triple ring burner must be correctly positioned (see figs. 18-19); the burner rib
must be located correctly in the burner base as shown by the arrow.
The burner correctly positioned must not rotate (fig. 19).
Then position the cap A and the ring B (fig. 19).
A
Fig. 18 Fig. 19
B
F
T
S
C
Fig. 17
S
T
