21
• Slide the appliance only half way into the cabinet so it is central in
the recess.
• Reach to the back left of the appliance top and adjust the
adjustment screw (“A” in Fig. 5) so that it reaches the underside of
the shelf above the appliance.
• Slide the appliance fully into the cabinet so it is central in the recess.
• Take care not to trap the power cable.
• Open the appliance door and fix the appliance in position using the
supplied screw in the installation hole (Fig. 6).
• Fit the supplied blanking plug to fill the screw hole.
Fig. 5
ADJUST HEIGHT
ADJUST SCREW A
TRIM KIT
,QVWDOODWLRQ+ROH
6FUHZ%
Fig. 6
