CDI TORQUE SURETEST - Page 49

CALIBRATION CHAPTER 5
Suggested Transducer Calibration Check Points, Bars, Hangers and Weights
(Sheet 2 of 2)
Part Bar Hanger Calibration Check Weights to Add Total
No. Range Length Weight Points Points (n) = more than 1 Weight
2000-11-02
20-250 ft lb 10.0" 15 lb 20.0 ft lb (2) 2 lb, 5 lb 24 lb
10.0" 15 lb 1 25.0 ft lb 25.0 ft lb 5 lb, 10 lb 30 lb
10.0" 15 lb 2 50.0 ft. lb 50.0 ft. lb 5 lb, (2) 20 lb 60 lb
10.0" 15 lb 3 100.0 ft. lb 100.0 ft. lb 5 lb, (2) 50 lb 120 lb
10.0" 15 lb 4 150.0 ft. lb 150.0 ft. lb 5 lb, (3) 20 lb, (2) 50 lb 180 lb
10.0" 15 lb 5 250.0 ft. lb 250.0 ft. lb 5 lb, (4) 20 lb, (4) 50 lb 300 lb
2000-12-02
60-600 ft lb 40" 15 lb 1 60.0 ft lb 60.0 ft lb 1 lb, 2 lb 18 lb
40" 15 lb 2 120.0 ft lb 120.0 ft lb 1 lb, (2) 10 lb 36 lb
40" 15 lb 3 240.0 ft lb 240.0 ft lb 2 lb, 5 lb, 10 lb, (2) 20 lb 72 lb
40" 15 lb 4 360.0 ft lb 360.0 ft lb 1 lb, 2 lb, 10 lb, (4) 20 lb 108 lb
40" 15 lb 5 600.0 ft lb 600.0 ft lb 5 lb, (3) 20 lb, (2) 50 lb 180 lb
2000-400-02
4-50 in lb 5" 1/2 lb 4.0 in lb 0.3 oz, 0.5 oz, 4 oz 0.8 lb
(4-in-1) 5" 1/2 lb 1 5.0 in lb 5.0 in lb 1/2 lb 1 lb
5" 1/2 lb 2 10.0 in lb 10.0 in lb 1/2 lb, 1 lb 2 lb
5" 1/2 lb 3 20.0 in lb 20.0 in lb 1/2 lb, 1 lb, 2 lb 4 lb
5" 1/2 lb 4 30.0 in lb 30.0 in lb 1/2 lb, 1 lb, (2) 2 lb 6 lb
5" 1/2 lb 5 50.0 in lb 50.0 in lb 1/2 lb, 1 lb, (4) 2 lb 10 lb
30-400 in lb 10" 1/2 lb 30.0 in lb 1/2 lb, 2 lb 3 lb
10" 1/2 lb 1 40.0 in lb 40.0 in lb 1/2 lb, 1 lb, 2 lb 4 lb
10" 1/2 lb 2 80.0 in lb 80.0 in lb 1/2 lb, 1 lb, (3) 2 lb 8 lb
10" 1/2 lb 3 160.0 in lb 160.0 in lb 1/2 lb, (3) 5 lb 16 lb
10" 1/2 lb 4 240.0 in lb 240.0 in lb 1/2 lb,1 lb, 2 lb, (4) 5 lb 24 lb
10" 1/2 lb 5 400.0 in lb 400.0 in lb 1/2 lb,1 lb (4) 2 lb, (6) 5 lb 40 lb
80-1000 in lb 10" 7-1/2 lb 80.0 in lb 1/2 lb 8 lb
10" 7-1/2 lb 1 100.0 in lb 100.0 in lb 1/2 lb, 2 lb 10 lb
10" 7-1/2 lb 2 200.0 in lb 200.0 in lb 1/2 lb, 2 lb, (2)5 lb 20 lb
10" 7-1/2 lb 3 400.0 in lb 400.0 in lb 1/2 lb, 2 lb, (2)5 lb, (2)10 lb 40 lb
10" 7-1/2 lb 4 600.0 in lb 600.0 in lb 1/2 lb, 2 lb, (2)5 lb, (4)10 lb 60 lb
10" 7-1/2 lb 5 1000 in lb 1000 in lb 1/2 lb, 2 lb, (2)5 lb, (4)10 lb, (2)20 100 lb
20-250 ft lb 10" 15 lb 20.0 ft lb (2) 2 lb, 5 lb 24 lb
10" 15 lb 1 25.0 ft lb 25.0 ft lb 5 lb, 10 lb 30 lb
10" 15 lb 2 50.0 ft. lb 50.0 ft. lb 5 lb, (2) 20 lb 60 lb
10" 15 lb 3 100.0 ft. lb 100.0 ft. lb 5 lb, (2) 50 lb 120 lb
10" 15 lb 4 150.0 ft. lb 150.0 ft. lb 5 lb, (3) 20 lb, (2) 50 lb 180 lb
10" 15 lb 5 250.0 ft. lb 250.0 ft. lb 5 lb, (4) 20 lb, (4) 50 lb 300 lb
5-6
